CHOOSING AND USING BRUSHES

POLYPROPYLENE BRUSH (PPL)
Used on all types of floors. Good resistance to wear and tear, and hot water (no greater than 50°C.). PPL is non-hygroscopic and therefore
retains its characteristics even when working in wet conditions.
ABRASIVE BRUSH
The bristles of this type of brush are charged with highly aggressive abrasives. It is used to clean very dirty floors. To avoid floor damage, work
only with the pressure strictly necessary.
BRISTLE THICKNESS
Thicker bristles are more rigid and are therefore used on smooth floors or floors with small joints.
On uneven floors or those with deep joints, it is advisable to use softer bristles which can enter the gaps more easily.
Remember that when the bristles are worn and therefore too short, they will become rigid and are no longer able to penetrate and clean deep
down. In this case, like with over-large bristles, the brush tends to jump.
PAD HOLDER
The pad holder is recommended for cleaning shiny surfaces.
There are two types of pad holder:
1. The traditional pad holder is fitted with a series of anchor points that allow the abrasive floor pad to be held and dragged while working.
2. the CENTRE LOCK type pad holder not only has anchor points, but also a snap-type central locking system in plastic that allows the abrasive
floor pad to be perfectly centred and held without any risk of it becoming detached. This type of pad holder is recommended above all for
machines with more than one brush, where the centring of the abrasive discs is difficult.
TYPE OF BRUSH (SCRUBBING VERSION)
CODE QTY Ø EXTERNAL
447244 2
447246 2
447248 2
447251 2
427709 1
427710 1
427711 1
427712 1
427713 1
TYPE OF BRUSH (SWEEPING VERSION)
CODE QTY
447963 2
447964 2
447965 2
437874 2

SYMBOLS USED ON THE MACHINE

Filter body position symbol:
Applied to the left-hand side of the machine to indicate the position of the solution tank's filter.
P
Extra pressure activation/deactivation lever position symbol:
Applied to the central brush head's extra pressure activation/deactivation lever.
R
Reverse gear activation/deactivation lever position symbol:
Applied to the reverse gear activation/deactivation lever.
Brush head body working position symbol:
Applied to the steering column to indicate the brush head control lever direction of rotation for bringing the brushes to their working
position.
TYPE OF
BRISTLE
Ø460mm PPL Ø0.6
Ø460mm PPL Ø0.9
Ø460mm ABRASIVE
Ø440mm -
Ø290mm PPL Ø0.3
Ø290mm PPL Ø0.6
Ø290mm PPL Ø0.9
Ø290mm ABRASIVE
Ø280mm -
Ø EXTERNAL LENGTH
200mm 856mm
200mm 856mm
200mm 856mm
450 -
WHITE CENTRAL BRUSH
BLACK CENTRAL BRUSH
CENTRAL BRUSH
CENTRAL PAD HOLDER
BLUE SIDE BRUSH
WHITE SIDE BRUSH
BLACK SIDE BRUSH
SIDE BRUSH
SIDE PAD HOLDER
TYPE OF BRISTLE
PPL 0.6mm CENTRAL BRUSH
PPL 0.9mm CENTRAL BRUSH
ABRASIVE CENTRAL BRUSH
PPL 1mm SIDE BRUSH
9
