TYPE OF BATTERY TO BE USED

The batteries must meet the requirements laid out in the norms: DIN/EN 60254-2 and IEC 254-2 series L. To carry out the work well the
machine must have a 36V power supply, we recommend using a 36V 360Ah/C

INSERTING THE BATTERIES IN THE MACHINE

To fit the batteries inside the machine, contact an FIMAP assistance centre technician.
WARNING: FIMAP declines all responsibility for any damage to property or injury persons in the event that the batteries are replaced by
an unauthorized technician.

BATTERY MAINTENANCE AND DISPOSAL

For battery maintenance and recharging, respect the instructions provided by the battery manufacturer.
When the batteries reach the end of their service life, they must be disconnected by a FIMAP assistance centre technician or by a specialised
and properly trained worker, and must be subsequently removed from the battery compartment using suitable lifting devices.
N.B.: dead batteries are classified as dangerous waste and as such must be delivered to an authorised body for disposal.

RECHARGING THE BATTERIES

The batteries must be charged prior to first use, and whenever they no longer provide sufficient power.
N.B.: Carefully read the Use and Maintenance Manual for the batteries you wish to use before charging.
1. Bring the appliance to the zone where the batteries are charged.
2. Make sure the machine has been secured (see the section titled
ATTENTION: Park the appliance in an enclosed place, on a flat surface; near the appliance there must be no objects that could either
damage it, or be damaged through contact with it.
ATTENTION: the room used to recharge the batteries must be adequately ventilated to prevent the accumulation of gases that leak from
batteries.
3. Get off the machine.
CAUTION: when getting down from the machine, do not place your foot on the scrubbing brush head or side brush head brush.
4. Grip the back of the seat (3) and turn the seat support plate to its maintenance position (Fig.4).
ATTENTION: to prevent the seat from rotating, insert the retainer (4) into the slot (5) (Fig.5).
5. Disconnect the electrical connector from the machine's general system.
ATTENTION: the following operations must be carried out by qualified personnel. An incorrect connection of the connector may cause a
malfunction of the device.
6. Connect the external battery charger cable to the battery connector.
N.B.: the coupling connector of the battery charger is consigned inside the bag containing this instruction booklet, and must be
assembled on the cables of the battery charger as indicated in the instructions.
ATTENTION: Before connecting the batteries to the battery charger, make sure it is suitable for the batteries you want to use.
N.B.: carefully read the use and maintenance instructions of the battery charger that is used for charging.
CAUTION: keep the recovery tank open for the duration of the battery recharging cycle to allow gas fumes to escape.
7. Once the recharge cycle has been completed, disconnect the battery charger's cable from the battery connector.
8. Connect the electrical system connector to the battery connector.
9. Grip the back of the seat (3) and turn the seat support plate to the working position.
10. Grip the handle (6) and lower the recovery tank to the maintenance position (Fig.7).
ATTENTION: to prevent the recovery tank from rotating, grip the handle (7) on the safety stop lever (8) and position the lever in the stop
slot (Fig.8).
traction battery box.
5
"SECURING THE MACHINE").
