Maximalfdv Series Overview; Maximalfdv Series Configuration Chart; Maximalfdv Series Features; Acm8Cb Access Power Controller Modules - Altronix Maximal Series Installation Manual

Altronix MaximalFDV Access Power/Controllers distribute and switch power to access control systems and
accessories. They convert a 220VAC (working range 198VAC - 256VAC), 50/60Hz input into sixteen (16)
independently controlled 12VDC or 24VDC PTC protected outputs. The outputs are activated by an open col-
lector sink or normally open (NO) dry trigger input from an Access Control System, Keypad, Push Button, REX
PIR, etc. Units will route power to a variety of access control hardware devices including: Mag Locks, Electric
Strikes, Magnetic Door Holders, etc. The FACP Interface enables Emergency Egress, Alarm Monitoring, or may
be used to trigger other auxiliary devices. The fire alarm disconnect feature is individually selectable for any or
all of the sixteen (16) outputs.
Nominal DC Output Voltage
9.7-
Maximal3FDV
13.2
9.7-
Maximal5FDV
13.2
Maximal7FDV
–
These units are suitable to power: sensors, electro-mechanical devices (e.g. electric door strikes).

ACM8CB Access Power Controller Modules:

• Sixteen (16) independently trigger controlled outputs. Output options:
a) Sixteen (16) Fail-Safe filtered power outputs.
b) Sixteen (16) Fail-Secure filtered power outputs.
c) Any combination of the above.
• Sixteen (16) Access Control System trigger inputs. Input trigger options:
a) Sixteen (16) normally open (NO) dry trigger inputs.
b) Sixteen (16) open collector inputs.
c) Any combination of the above.
• Sixteen (16) unswitched filtered aux. power outputs (outputs are rated @ 2.5A).
• Red LEDs on ACM8CB board indicate individual outputs are triggered (relays energized).
• Fire Alarm disconnect (latching or non-latching) is individually selectable for any or all of the
sixteen (16) outputs.
Fire Alarm disconnect input trigger options:
a) Normally open (NO) or normally closed (NC) dry trigger input.
b) Polarity reversal input from FACP signaling circuit.
• Green LED on ACM8CB board indicates FACP disconnect is triggered.
• FACP output relay indicates that FACP input is triggered (form "C" contact rated @ 1A/28VDC).
• eFlow Power Supply/Charger board provides common power for both ACM8CB Access Power Controller
boards (factory wiring) and all connected access control devices (field wiring).
• ACM8CB board main fuses are rated @ 10A. Output PTCs are rated @ 2.5A.
Maximal3FDV / Maximal5FDV / Maximal7FDV Access Power Controllers (PTC)

MaximalFDV Series Overview:

MaximalFDV Series Configuration Chart:

[DC] [Aux]
19.8- 10.03- 20.19-
26.4 13.2 26.4
10.03-
–
13.2
19.8- 20.28-
–
26.4 26.4

MaximalFDV Series Features:

Maximum Supply
Current for
Main and Aux.
Outputs on Power
Supply board and
ACM8CB Access
Power Controller's
outputs (A)
12VDC @ 4.6A or
24VDC @ 5.2A
– 8.6A
9.2A
5A/
16 2.1A 2.5
250V
5A/
16 2.1A 2.5
250V
6.3A/
16 2.7A 2.5
250V
10A/ 10A/
32V 250V
15A/ 10A/
32V 250V
15A/ 10A/
32V 250V
