WATERCO POOL HEAT PUMP
WATERCO THERMOPOMPE CHAUFFE-PISCINE
Installation and
Operation Manual
Manuel d'installation
et d'utilisation
WARNING
This equipment must be installed and serviced by a qualified technician.
!
Improper installation can create electrical hazards which could result in property
damage, serious injury or death. Improper installation will void the warranty.
Cet équipement doit être installé st réparé par un technicien qualiflié.
Une mauvaise installation peut entraîner des risques électriques qui pourraient
provoquer des dommages, des blessures graves ou la mort. Une installation
inadéquate annulera la garantie.
Notice to Installer / Avis à l'installateur
This manual contains important information about the installation, operation and
safe use of this product. Once the product has been installed this manual must
be given to the owner/operator of this equipment.
Ce manual contient des informations importantes sur l'installation, I'exploitation
et l'utilisation sécuritaire de ce produit. Une fois que le produit a été installé, ce
manuel doit être remis à l'acheteur et/ou utilisateur de cet équipement.
25kW
www.waterco.com.au
