- Page 1 DC INVERTER Swimming Pool Heat Pump Applicable Models:Electroheat ECO V 25KW...
- Page 2 Swimming Pool Heat Pump THIS MANUAL MUST BE READ AND UNDERSTOOD BY A QUALIFIED PERSON OR PERSONS BEFORE INSTALLATION CONTENT Introduction of Swimming Pool Heat ool Hea Safety Precautions Technical Specifications Dimensions Installation Electric Circuit Drawing Controller Maintenance & Trounbleshooting Parameter Number and Description Table...
- Page 3 Swimming Pool Heat Pump Introduction of Swimming Pool Heat Pump Thank you for purchasing our reversible heat pump water heater for your Swimming Pool/Pond. Our heat pump was produced in accordance with the current European Standard and it is now ready to be used. Please read this manual carefully before install the heat pump, otherwise it may lead to damage to the heat pump or may injure operators as well as cause financial loss.
- Page 4 Swimming Pool Heat Pump...
- Page 5 Swimming Pool Heat Pump 12)Cut off the power supply before maintaining the unit, and the maintenance work should be carried out by professional. 13)If any abnormity occurs in the heat pump, such as abnormal noise or burned smell, cut off the power supply immediately, and contact professionals for check and repair.
- Page 6 Swimming Pool Heat Pump Model Electroheat ECO V 25KW 24.1～6.1 Heating Capacity Air 15 5.95～0.85 Heating Input ℃ /Water 27.2～3.95 Normal Current 26℃ 4.05～7.2 V/Ph/Hz 230V/1Ph/50Hz Power Supply 15℃～40℃ Setting Temp. Range ℃ -5℃～43℃ Running Temp. Range ℃ Titanium PVC Tank...
- Page 7 Swimming Pool Heat Pump...
- Page 8 Swimming Pool Heat Pump Up flow more than 2000mm air inlet air inlet Horizontal View more than more than 1000mm 1000mm more than air inlet 1000mm air inlet air inlet Vertical View more than more than 1000mm 1000mm enough space for maintenance...
- Page 9 Swimming Pool Heat Pump Pool Connection Diagram Diagram 1 Check-valve Filter Chlorinator P-trap Check-valve Water Pump Swimming Pool Diagram 2 Heat Pump Water processor Side connection valve Power cable inlet Condensed water draining pipe Water pump Filter Pool water inlet Discharge water to pool Draining nozzle Remarks:...
- Page 10 Swimming Pool Heat Pump...
- Page 11 Swimming Pool Heat Pump...
- Page 12 Swimming Pool Heat Pump...
- Page 13 Swimming Pool Heat Pump ◆ Button Operation: On/Off: Press the “ ” button on the main interface to switch between the On/Off status; Mode switching: Press the “M” button on the main interface to switch between the operation modes; Button locking: Press and hold the “▲” and “▼” buttons for 5S at the same time on the main interface to lock the buttons, and the icon will appear on the screen when the buttons are locked.
- Page 14 Swimming Pool Heat Pump...
-
Page 15: Maintenance And Troubleshooting
Swimming Pool Heat Pump Maintenance and Trouble Shooting Maintenance The heat pump water heater is an advanced clean and ventilated. Regularly clean the equipment with high automization. The evaporator to keep high heat exchanging reliability and operation life of the heat pump can efficiency. - Page 16 Swimming Pool Heat Pump Press and hold the “ ” button for 5s to enter the status quer y : Query Meaning Display Range Code Inlet water temperature -20~99℃ Outlet water temperature -20~99℃ Ambient temperature -20~99℃ Exhaust temperature 0~125℃ Return air temperature -20~99℃...
-
Page 17: Parameter Number And Description Table
Swimming Pool Heat Pump Parameter Number and Description Table Press and hold the “Set” key for 5s to enter the password setting interface; enter “0814” to enter the parameter query interface: Setting Code Parameter Name Adjustment Range Initial Value Air conditioning temperature 2℃~18℃... - Page 18 Swimming Pool Heat Pump Exhaust setting TP2 50~125℃ 105℃ Exhaust setting TP3 50~125℃ 110℃ Exhaust setting TP4 50~125℃ 120℃ Current I limit 5~50A Current I down 5~50A Current I shutdown 5~50A Exhaust limit main expansion valve 50~125℃ 61℃ down 1 Exhaust limit main expansion valve 50~125℃...
