Appendix 3: Password Functions (P.296, P.297)
Registering a four-digit password can restrict parameter reading and writing. You can set these parameters
when P.160 = 0.
Note: When P.296 is set to something other than 9999, then P.297 is always available to enter a password,
regardless of the setting for P.160.
Table 82: Implement Password Protection
Parameter Name
P.296 Password Lock Level
P.297 Password
Unlock/Lock

Parameter Reading and Writing Restriction Level

P.296 controls the level of reading and writing restriction.
Table 83: Parameter Reading and Writing Restriction (P.296)
P.296 Setting
PU Operation Mode Command
Read
9999 Enabled
1, 101 Enabled
2, 102 Enabled
3, 103 Enabled
4, 104 Restricted
5, 105 Restricted
6, 106 Enabled
1. Parameter access from a unit where the parameter is written in the PU Manual Operation mode is restricted.
2. Parameter access in NET Operation mode with RS-485 communication is restricted.
3. If the parameter reading is restricted by P.160, P.296 is unavailable for reading, even when enabled.
4. If the parameter writing is restricted by P.77, P.296 is unavailable for writing, even when enabled.
Default Range
9999 1 to 6, 101 to 106
9999
9999 1000 to 9998
(0)
(0 to 5)
(9999)
3 4
Write
Enabled
Restricted
Restricted
Enabled
Restricted
Restricted
Enabled
VFD68 Variable Frequency Drives
Description
Select the restriction level of parameter
reading and writing when a password is
required.
No password lock
Register a four-digit password
(reading only)
Valid when P.296 = 1 to 6
Displays password unlock error count
(reading only)
Valid when P.296 = 101 to 106
No password lock (reading only)
1
NET Mode Operation Command
3
Read
Enabled
Enabled
Enabled
Enabled
Restricted
Enabled
Restricted
88
2
4
Write
Enabled
Restricted
Enabled
Restricted
Restricted
Enabled
Restricted
