Dimensions for VFD68Dxx Drives

Table 9: Dimensions for VFD68Dxx Drives, mm (in.)
VFD Model
VFD68DFM
VFD68DGM
VFD68DHM
VFD68DJN
VFD68DKN
VFD68DLN
Figure 4: Dimensions for VFD68Dxx Drives, mm (in.)
H H1
150 (5-15/16) 138 (5-7/16)
VFD68 Variable Frequency Drives
W
140 (5-1/2)
228 (8-11/16)
12
W1 D
128 (5-1/16) 136 (5-3/8)
208 (8-3/16) 148 (5-13/16)
