Dimensions for VFD68Bxx and VFD68Cxx Drives

Table 7: Three-Phase 230 VAC Models, mm (in.)
VFD Model
VFD68BBB
VFD68BCB
VFD68BDC
VFD68BFD
VFD68BGG
VFD68BHG
VFD68BJK
VFD68BKL
VFD68BLL
VFD68BMP
VFD68BNP
Table 8: Three-Phase 460 VAC Models, mm (in.)
VFD Model
VFD68CDF
VFD68CFF
VFD68CGG
VFD68CHH
VFD68CJJ
VFD68CKL
VFD68CLL
VFD68CMP
VFD68CNP
Figure 3: Dimensions for VFD68 Drives, 230–460 VAC Models
H H1
128 (5.04) 118 (4.65)
150 (5.91) 138 (5.43)
260 (10.23) 244 (9.61)
H H1
128 (5.04) 118 (4.65)
150 (5.91 138 (5.43)
260 (10.23) 244 (9.61)
VFD68 Variable Frequency Drives
W
68 (2.68)
108 (4.25)
170 (6.69)
220 (8.66)
220 (8.66)
W
108 (4.25)
220 (8.66)
220 (8.66)
11
W1 D
56 (2.20) 80.5 (3.17)
112.5 (4.43)
132.5 (5.22)
96 (3.78) 135.5 (5.34)
158 (6.22) 142.5 (5.61)
208 (8.19) 155 (6.10)
195 (7.68) 190 (7.48)
W1 D
96 (3.78) 129.5 (5.10)
135.5 (5.34)
155.5 (6.12)
165.5 (6.52)
208 (8.19) 155 (6.10)
195 (7.68) 190 (7.48)
