7. Press to show 12.5 (default value of P. 32).
SET
8. Press and hold until 9999 appears (9999 indicates that the motor is set to run at minimum speed and
not turn off during a low pressure condition).
9. Press and hold for two seconds to set the new value.
SET
10. Press again to advance to the next parameter.
SET
11. To change additional parameters, press
Select and Change P.90x Parameters
12. To change parameter 902 (screen a) or 902 (screen b), press
13. Press . P.000 appears. (The underline indicates a blinking character.)
SET
14. Press once to show P.900.
15. Press twice until P.900 appears.
SET
16. Press twice to display P.902.
17. Press to show P.90xa. (The default value of P.902a is 12.5 Hz.) Press
SET
value.
18. Press and hold for two seconds to set the P.90xa value and show the actual input % for P.90xb.
SET
19. Press once to view the default setting (38% for P.902b). Press
20. Press and hold for two seconds to set the new value.
SET
21. Press again to advance to the next parameter.
SET
22. Press or to display the next P.90x parameter that needs to be changed. Repeat Steps 17–21.
Exit the Parameter Adjustment Mode
23. When done, cycle power or press
appears on the display.
24. Press until 0.00 MON EXT appears on the display.
MODE
25. Use the jumper wire to connect terminal SD to terminal STF to run the motor using analog inputs.
or .
until PU PU appears on the display, then press
MODE
VFD68 Variable Frequency Drives
55
until Pr.. PU appears on the display.
MODE
or to change the
or to change the value.
until OP.nd EXT
