Motion Detection Configuration - Digital Watchdog MEGApix Flex DWC-PVX16W2 User Manual

Setup - Event Setup

Motion Detection Configuration

Motion Detection - It shows the Motion event status.
Event Alert Icon( ) appears if 'Motion Detection' is activated.
VIN Source - Select the Video 1 ~ Video 4 and Set the video setup
Click 'save' to set the other video setting.
Area - Set the motion detected area.
You can set up to four areas.
Activation - Enable or Disable motion detection function.
Sensitivity - Define the sensitivity of motion detection. If High value is selected, it will detect very small motion while it becomes
relatively insensitive when Low value is selected.
Click 'Save' to save the current settings.
Click 'Cancel' to return to the previous setting.
54
