If you receive this error message, rename the rbf file adding the word metis to the file name. In my
example I added it to the end.
10.7.2 Assign Static IP Address using HPSDRBootloader
1. Choose the correct Computer Interface and then Test for Bootloader.
2. Click on IP from the menu.
3. Click on ReadIP to read the current IP address of the radio.
4. Enter the new IP address in the IP Address fields.
5. Click on Write IP to update the IP address in the radio.
To revert back to using DHCP or APIPA enter 0.0.0.0 in the IP Address fields and click on Write IP.
10.7.3 HPSDRProgrammer for Protocol 2
It is also possible to use the HPSDRProgrammer utility to reprogram the flash memory.
The update files are available from https://github.com/TAPR/OpenHPSDR‐Firmware. Operation with
THETIS will require Protocol 2 firmware. Firmware Update files will have the ".rbf" suffix. The
HPSDRProgrammer utility is specifically designed so you cannot inadvertently overwrite or damage
the lower bootloader addresses
1.
Download the HPSDRProgrammer for Windows: https://github.com/TAPR/OpenHPSDR‐
Protocol2‐Programmers/releases
2. Exit from the THETIS program, if it was open.
3. Unzip the folder. There is no formal installer.
3. Open a Windows command prompt ("DOS") window.
ANDROMEDA Manual Page 53 of 56
