In this form, the softkey menus at the bottom of the screen in ANDROMEDA view can be edited. A
menu consists of a set of 8 softkey settings.
Menu number Displays all the current menu entries. Menus (with a set of 8 softkey settings)
can be inserted and deleted.
To select settings for a particular menu, use the mouse to click in the number
for that menu.
Menu button Displays the action that has been assigned to this softkey.
action
To change the softkey action: click in the cell, twice. A combo box control will
appear. Click its down arrow to show a list of the options that can be assigned.
Click an option to select it.
Button Text The text that will be shown on the softkey. This is selected automatically when
a new softkey setting is chosen.
Some menu types have the text altered to indicate RX1/RX2 and the current
state. However for some controls it may be appropriate to edit the default
text. For example "Change menu row" softkey is used to step between menus;
it may be appropriate to edit its text to show the name of the current menu
or new menu, according to preference.
Selected RX This setting allows the softkey to be assigned to a specific receiver. This
control is also a combo box and is used in the same way.


Link to Menu This gives a destination menu number for the "change menu row" softkey.
Insert Menu and Delete Menu inset and delete, respectively, groups of 8 controls. Using these you
can make your own menu structure. Note that the form tries to alter "link to menu" values if a menu
is inserted or deleted. It will try to leave the link to the row that had been linked before the insertion
or deletion. However it is important to check that the links are what you intend!
ANDROMEDA Manual
Some softkeys are not associated with a receiver (eg "Clear RIT") and
"default setting" should be selected
Receiver controls can be assigned to RX1 only, RX2 only, or if "default
setting" is chosen the control will choose RX1 if VFO A is selected, or RX2
if VFO B is selected.
