5.9.4 TX Menu
TX Menu Press to advance to the next menu
Mode Settings Opens the Mode settings form to access a range of (mostly TX) settings for the
Form current operating mode
Puresignal form Opens the Puresignal form
Puresignal Selects Puresignal on or off
select
MOX Toggles between TX and RX modes
TUNE Toggles between TUNE and RX modes
PS 2 Tone Test Initiates a 2 tone TX test to enable Puresignal to optimise linearity
‐‐‐ Not assigned
5.9.5 Display Menu
Display Menu Press to advance to the next menu
RX Meter Steps through the available RX meter modes; shows the current setting
TX meter Steps through the available TX meter modes; shows the current setting
RX display Steps through the available display modes for the centre part of the display
Centre Display Centres the panadapter/waterfall display at the current VFO frequency
Display Form Opens the Display form
Zoom Steps through a series of zoom settings for the panadapter/waterfall display
‐‐‐ Not assigned
5.9.6 Audio Menu
Audio Menu Press to advance to the next menu
Quick record Initiates a "quick record" function to record RX or TX audio
audio
Quick play Initiates a "quick replay" or recorded audio to RX or TX
audio
‐‐‐ Not assigned
Audio rec/play Opens the audio record/replay form
form
VAC1 Toggles PC Virtual Audio Channel for RX1
VAC2 Toggles PC Virtual Audio Channel for RX2
‐‐‐ Not assigned
5.9.7 Setup Menu
Setup Menu Press to advance to the next menu
Duplex Toggles Duplex operation on/off
TX Monitor Toggle TX monitor on/off
RX2 Toggle RX2 on/off
Sub RX Toggles the RX1 sub‐receiver on/off
Equaliser form Opens the RX & TX equaliser form
Setup Form Opens the Setup form
Extended Menu Opens a further, rarely access menu
ANDROMEDA Manual Page 22 of 56
