2.2.2 RX1 AF/RF Gain
Pressing the upper knob toggle RX1 Mute on/off
Turning the upper knob adjusts the RX1 AF gain or "volume". A slider pops up to
the right of the multi‐meter to indicate the current position.
Turning the lower knob adjusts the RX1 AGC, which behaves similarly to RF gain in
an analogue receiver. A green bar is normally shown in the spectrum view, which
should be adjusted to sit just above the noise floor. A slider pops up to the right
of the multi‐meter to indicate the current position.
If the RX1 AF encoder knob is pressed down and turned while held down, the PC
&
display brightness is changed. The brightness setting will be saved and restored
every time the radio is powered up.
2.2.3 RX2 AF/RF Gain
Pressing the upper knob toggle RX2 Mute on/off
Turning the upper knob adjusts the RX2 AF gain or "volume". A slider pops up to
the right of the multi‐meter to indicate the current position.
Turning the lower knob adjusts the RX2 AGC, which behaves similarly to RF gain in
an analogue receiver. A green bar is normally shown in the spectrum view, which
should be adjusted to sit just above the noise floor. A slider pops up to the right
of the multi‐meter to indicate the current position.
2.2.4 Drive/Multifunction
Pressing the upper knob toggles the multifunction knob between selecting the
value of a setting, and choosing which setting is operated.
Press the knob to begin selecting another function. Turn the knob to choose the
function required (it is shown in the status bar). Press again to select that
function.
The multifunction knob can be selected to operate one of many functions. The
currently selected function is shown in the Thetis status bar.
Turning the lower knob adjusts the TX Drive level setting the maximum output
power. This is expressed as a % of full power. A slider pops up to the right of the
multi‐meter to indicate the current position.
ANDROMEDA Manual Page 12 of 56
