1. There is a button bar menu item to step the antenna. Each press will step both RX and TX
through the sequence ANT1‐ANT2‐ANT3‐ANT1 etc
2. By clicking on the antenna displays in the status bar you can select ANT1, ANT2, ANT3 for RX
and TX independently.
3. If you need to use the other antenna input, you will need to use the setup form.
5.9 Using the Softkey Menus
The 8 softkey buttons on the bar at the bottom of the screen form a series of menus to access the
functions of the radio. Each set of 8 buttons forms a menu, with the menu name at bottom left;
pressing that button moves to the next menu in sequence.
After 10 seconds of inactivity, the "Quick" menu will be selected so that it is readily at hand.
The remaining 7 buttons either have a function, or show ‐‐‐ is there is no assigned function. Some
will be highlighted if they control an on/off function which is currently enabled. Some show
functions for RX1 or RX2, and the active receiver will be shown. The menus are as follows:
5.9.1 Quick Menu
Quick Menu Press to advance to the next menu
NR Noise reduction. Steps through off, NR and NR2 modes.
NB Noise blanking. Steps through off, NB and NB2 modes.
SNB Spectral Noise Blanker
ANF Automatic Notch Filter
AGC Steps through the available AGC speeds: fixed/long/slow/medium/fast/custom
Attenuation Steps the RX attenuator in 6dB steps
Antenna Step Steps through the 3 main antenna inputs
5.9.2 RX Menu
RX Menu Press to advance to the next menu
Diversity Enables or disables receiver diversity
Diversity Form Opens the diversity form
Gain Form Opens the gain form (showing settings for many controls)
Filter Form Opens the filter bandwidth form
RX Mute Toggles RX mute on or off
RX Ant (not yet implemented)
‐‐‐ Not assigned
5.9.3 VFO Menu
VFO Menu Press to advance to the next menu
Band Form Opens the band form for band changes
Mode form Opens the mode form for mode changes
Bandstack Form Opens the Bandstack form to edit the available Bandstack memories
Swap A <‐> B Swap the A and B VFO settings
Tune Step Form Opens the Tune Step form to change the frequency per tune step
Bandstack Steps through the available Bandstack memories for the current band
‐‐‐ Not assigned
ANDROMEDA Manual Page 21 of 56
