10. If you are intending to use the serial output from the
Test Suite or output lap timing parameters, go to
Output Mode to either VBOX Stream (live testing with VBOX Test Suite) or Lap Timing.
Note: Ensure correct hardware connections are made.
11. Press the Exit Button
to return to the Lap Timing screen.
12. Take the vehicle outside and wait for the VBOX Touch to gain satellite lock. The
as solid green
, solid orange
or solid purple
depending on whether you have a VBOX Touch RTK unit.
Note: The first time that the unit is used, it may take up to 10 – 15 minutes to fully acquire satellites. After this, it
will usually take 1 – 2 minutes to acquire satellites.
top CAN/Serial port
Serial Output
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/Quick_Start_Guides/
to conduct Online Testing
within the Serial Port Settings and change the
Satellite Icon
VBOX_Touch_Lap_Timing_Mode_-_Quick_Start_Guide
with VBOX
should display
