 Product Specifications
CPU Support
Chipset
Memory
BIOS
I/O Chip
Display
Storage
USB
Audio
Expansion
Cooling
Switch & LED
Watchdog Timer
Hardware Monitor
Real Time Clock
Power
Environment
Dimensions
Weight
Certifications
QBOX Mini-2000 User's Manual
®
Intel Atom™ Processor N2600 (1M Cache, 1.60 GHz)
®
Intel NM10 Express Chipset
DDR3 SO-DIMM Socket ( 2GB max )
AMI uEFI BIOS
1x 16Mb SPI flash ROM
Fintek F71869ED Super I/O
1x HDMI Connector
1x mSATA
3x USB2.0 type A Connectors
Realtek ALC662 HD Codec
1x Phone Jack for both Line-Out & Mic-In
1 x Mini PCI-Express Socket for WiFi module
Fanless
1x Power On/Off Button ( With Power LED)
1x Clear CMOS Switch
1x HDD LED Indication
1x WiFi LED Indication
Programmable WDT to generate System reset event
Temperature & Voltage Monitoring
NM10 integrated RTC
DC 12V-19V Input
Operating: 0°C to 40°C
137.96 x 87.82 x 18.95 mm ( D x W x H )
193.6 (g)
CE, FCC Class A

Table 1 QBOX Mini-2000 Specification
