Installing the SmartSwitch 9000 Module
Metal Back-Panel
2-6
Module Guides
Warning:
Ensure that the circuit card is between the card guides.
Lock down the top and bottom plastic tabs
at the same time, applying even pressure.
Figure 2-3. Installing the MicroLAN Module
Jack for ESD
Wrist Strap
Module
Plastic Tab
