Installing the SmartSwitch 9000 Module

Setting the Module Card DIP Switch

An eight position DIP switch is located on the module card as shown in
Figure 2-2. The functions of this switch are listed in Table 2-1.
See the Cautions at the end of this table.
1
Do not toggle Switch 8 unless you intend to reset the user configured passwords
to their factory default settings.
!
2
CAUTION
Do not toggle Switch 7 unless you intend to reset the user parameters to the
factory default settings.
2-4
Table 2-1. Function of DIP Switch
Switch Function
Clear
8 Password
Clear
NVRAM
7
Force BootP
Download
6
5 Reserved
4 Reserved
3 Reserved
2 Reserved
1 Reserved
When toggled, this switch clears user-entered
1
passwords stored in NVRAM, and restores the
default passwords. Once reset you can use the
defaults or enter new passwords.
The module uses NVRAM to store user
2
entered parameters such as IP addresses,
device name, etc. To reset these parameters to
the factory defaults, toggle this switch. Once
reset, you can use the defaults or enter new
parameters which are stored in NVRAM when
the module is powered down, and remain
there until the switch is toggled again.
Toggling this switch after pulling the board out
of the SmartSwitch 9000, clears download
information from NVRAM and forces image
files to be downloaded from the station
configured to act as that modules' BOOTP
server.
For Factory Use Only
For Factory Use Only
For Factory Use Only
For Factory Use Only
For Factory Use Only
Description
