Management Information Base (MIB) Support
The 9T125-08 provides MIB support including:
• IETF MIB II (RFC 1213)
• IETF Bridge MIBs (RFC 1493 and 1525)
• IEEE 802.5 Token Ring MIB (RFC 1231)
• Cabletron Enterprise MIBs
• RMON
For a complete list of supported MIBs, refer to the release notes provided in the
NOTE module package.
Ring Security
This feature prevents unauthorized stations from attaching to the ring. Using Local or
Remote Management, the module may be configured as to which MAC addresses are
allowed to operate on the ring.
LANVIEW LEDs
The 9T125-08 uses LANVIEW – the Cabletron Systems built-in visual diagnostic and status
monitoring system. With LANVIEW LEDs, you can quickly identify the device, port, and
physical layer status at a glance.
Hot Swapping
The 9T125-08 can be installed or removed from the chassis while the SmartSwitch 9000 is
powered up without affecting the operation of the remaining modules in the chassis.
Webview
Management of the 9T125-08 may be accomplished using Cabletron's WEBVIEW. This
allows managing the module though an on-line browser.

Related Manuals

The manuals listed below should be used to supplement the procedures and technical data
contained in this manual.
SmartSwitch 9000 Installation Guide
SmartSwitch 9000 Operations Guide
SmartSwitch 9000 9C300-1 Environmental Module User's Guide
SmartSwitch 9000 9C214-1 AC Power Supply User's Guide
SmartSwitch 9000 Local Management User's Guide
Introduction
1-3
