SmartSwitch 9000
9F120-08 / 9F122-12 / 9F125-08
Local Management Appendix
9031372-01

Advertisement

loading
Need help?

Need help?

Do you have a question about the Expansion module 9F120-08 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cabletron Systems Expansion module 9F120-08

Summary of Contents for Cabletron Systems Expansion module 9F120-08

  • Page 1 SmartSwitch 9000 9F120-08 / 9F122-12 / 9F125-08 Local Management Appendix 9031372-01...

  • Page 3: Module Specific Information

    9F120-08 / 9F122-12 / 9F125-08 Module Specific Information Introduction This appendix contains local management information that is specific to the 9F120-08, 9F122-12 and 9F125-08 MicroLAN modules. Default Interface Codes The Default Interface field on the General Configuration Screen allows you to enter a number (one through three).
  • Page 4 9F120-08 / 9F122-12 / 9F125-08 Module Specific Information FNB Resource Configuration Codes All of the MicroLAN Modules described in this appendix physically attach to the FNB-1 and the FNB-2 on the SmartSwitch 9000 backplane. By default, the module inserts into four rings (the primary and secondary rings of the FNB-1 and the FNB-2).
  • Page 5 Table 2. 9F12x-xx MicroLAN Module FNB Resource Configuration Codes Configuration FDDI Connections FNB 1 Pri. (MAC) Byp. , FNB 2 Pri. (No MAC) Byp. FNB 1 Pri. (MAC) Byp. , FNB 2 Pri. (No MAC) Ins. FNB 1 Pri. (MAC) Ins. , FNB 2 Pri.
  • Page 6 9F120-08 / 9F122-12 / 9F125-08 Module Specific Information Table 2. 9F12x-xx MicroLAN Module FNB Resource Configuration Codes (Continued) Configuration FDDI Connections FNB 1 Pri. (No MAC) Ins. , FNB 2 Pri. (MAC) Byp. FNB 1 Pri. (No MAC) Ins. , FNB 2 Pri.
  • Page 7 Table 2. 9F12x-xx MicroLAN Module FNB Resource Configuration Codes (Continued) Configuration FDDI Connections FNB 1 Pri. (No MAC) Byp. , FNB 2 Sec. (MAC) Byp. FNB 1 Pri. (No MAC) Byp. , FNB 2 Sec. (MAC) Ins. FNB 1 Pri. (No MAC) Ins. , FNB 2 Sec.
  • Page 8 9F120-08 / 9F122-12 / 9F125-08 Module Specific Information Table 2. 9F12x-xx MicroLAN Module FNB Resource Configuration Codes (Continued) Configuration FDDI Connections FNB 1 Sec. (MAC) Ins. , FNB 2 Pri. (No MAC) Byp. FNB 1 Sec. (MAC) Ins. , FNB 2 Pri. (No MAC) Ins. FNB 1 Sec.
  • Page 9 Table 2. 9F12x-xx MicroLAN Module FNB Resource Configuration Codes (Continued) Configuration FDDI Connections FNB 1 Sec. (MAC) Byp. , FNB 2 Sec. (No MAC) Byp. FNB 1 Sec. (MAC) Byp. , FNB 2 Sec. (No MAC) Ins. FNB 1 Sec. (MAC) Ins. , FNB 2 Sec.
  • Page 10 9F120-08 / 9F122-12 / 9F125-08 Module Specific Information Table 2. 9F12x-xx MicroLAN Module FNB Resource Configuration Codes (Continued) Configuration FDDI Connections FNB 1 Sec. (No MAC) Ins. , FNB 2 Sec. (MAC) Byp. FNB 1 Sec. (No MAC) Ins. , FNB 2 Sec.

  • Page 11: Module Specific Configuration Screen

    Module Specific Configuration Screen In the FNB Resource Configuration Screen, you determine which of the two FNB rings contains the MAC. The 9F120 MicroLAN Module Specific Configuration Screen allows you to assign one of the two FNB rings (either the ring that contains the MAC or the ring that does not contain the MAC) to each of the module’s M- ports.
  • Page 12 9F120-08 / 9F122-12 / 9F125-08 Module Specific Information...
