Cabletron Systems SmartSwitch 6000 User Manual page 149

The following definitions explain each field of the RMON Statistics
screen:
RMON Index (Read-only)
This field displays the current Ethernet interface for which statistics are
being shown. The 6E123-50 and 6E133-49 have an embedded RMON
agent that gathers statistics for each interface on the module.
Data Source (Read-only)
This field displays the source of the statistics data that is currently being
displayed on the screen.
RMON index is Interface 1 (ENET 1) by displaying the name IfIndex.1.
If the screen was displaying RMON statistics for Interface 2 (ENET 2),
the name displayed would be IfIndex.2.
Owner (Read-only)
This field displays the name of the entity that configured this entry.
Status (Read-only)
The Status field displays the current operating status of the displayed
interface. This field will display "Valid" or "Invalid".
Drop Events (Read-only)
This field displays the total number of times that the RMON agent was
forced to discard frames due to the lack of available switch resources.
The Drop Events field does not display the number of frames
NOTE
dropped, it only displays the number of times that the RMON
agent was forced to discard frames.
Collisions (Read-only)
This field displays the total number of collisions that have occurred on
this interface.
Broadcast Pkts (Read-only)
The Broadcast Pkts field displays the total number of good frames that
were directed to the broadcast address. The value of this field does not
include multicast frames.
6E123-50 and 6E133-49 User's Guide
Figure 5-37 shows that the data source for this
RMON Statistics Screen
5-103
