5.22.2 Image File Download Using RUNTIME

Set the 6E123-50 and 6E133-49 to download to FLASH using RUNTIME
as follows:
1. Use the arrow keys to highlight the Download Method field.
2. Use the SPACE bar to select RUNTIME.
3. Use the arrow keys to highlight the Reboot After Download field.
4. Use the SPACE bar to select either YES or NO. Select YES if you
want the module to reboot after the download is completed. Select NO
if you want the module to store the new image in FLASH memory
until the module is manually reset.
5. Use the arrow keys to highlight the TFTP Gateway IP Addr field.
6. Set the IP address of the TFTP gateway server (this defaults to the
same IP address as that set in the TFTP Gateway IP Addr field on the
General Configuration screen).
7. Use the arrow keys to highlight the Download Server IP field.
8. Enter the IP address of the TFTP server using the DDN format.
For example: 134.141.79.121
9. Use the arrow keys to highlight the Download File Name field.
10. Enter the complete pathway and file name of the image stored on the
download server.
For example: /tftpboot/6E128.fls
11. Use the arrow keys to highlight EXECUTE at the bottom of the screen
and press ENTER. The message "RUNTIME DOWNLOAD. WILL
COMMIT TO FLASH." displays in the event message line at the top
of the screen and the new image is downloaded into FLASH memory.
6E123-50 and 6E133-49 User's Guide
Flash Download Screen
5-79
