Chapter 5: Local Management
Current Oper. Mode (Read-only)
This field displays the current operating mode of ports 5 and 6.
Depending on the interface installed (100BASE-FX or 100BASE-TX)
this field displays the following:
• With a 100BASE-FX interface: 100Base-FX or 100Base-FXFD (full
duplex).
• With a 100BASE-TX interface: Unknown, 10Base-T, 10Base-TFD
(full duplex), 100Base-TX, or 100Base-TXFD (full duplex).
Desired Oper. Mode (Toggle)
This field allows the user to select the desired operational mode for an
interface in port 5 or 6. The field toggles between 100BASE-FX and
100BASE-FXFD (full duplex) when an FE-100FX or FE-100F3 is
installed. Section 5.21.1
FE-100FX or FE-100F3.
In normal operation, the port with an FE-100TX installed
NOTE
automatically establishes a link with the device at the other end
of the segment without requiring user setup. However, Local
Management provides the user with the option of manually
configuring that port.
If an FE-100TX is installed, the field steps to Auto-Negotiation,
10BASE-T, 10BASE-TFD (full duplex), 100BASE-TX, and
100BASE-TXFD (full duplex). In normal operation, the port with an
FE-100TX installed is capable of auto-negotiating the operational mode
and no further user setup is required.
configure an FE-100TX.
5-72
describes how to configure a port with an
Section 5.21.3
6E123-50 and 6E133-49 User's Guide
describes how to
