Management

Table 1-1 Description of Mini-GBICs (Continued)
Mini-GBIC
MGBIC-08
MGBIC-02
Management
Management of the module can be either in‐band or out‐of‐band. In‐band remote
management is possible using Telnet, Enterasys Networks' NetSight
application, or the WebView application. Out‐of‐band management is provided through
the RJ45 COM (Communication) port on the front panel using a VT100 terminal or a
VT100 terminal emulator.

Switch Configuration Using WebView

Enterasys Networks' HTTP‐based Web management application (WebView) is an
intuitive web tool for simple management tasks.

Switch Configuration Using CLI Commands

The CLI commands enable you to perform more complete switch configuration
management tasks.
For CLI command set information and how to configure the module, refer to the
SecureStack C2 Configuration Guide.

Standards Compatibility

The switches are fully compliant with the IEEE 802.3‐2002, 802.3ae‐2002, 802.1D‐1998, and
802.1Q‐1998 standards. The switches provide IEEE 802.1D‐1998 Spanning Tree Algorithm
(STA) support to enhance the overall reliability of the network and protect against "loop"
conditions.

LANVIEW Diagnostic LEDs

LANVIEW diagnostic LEDs serve as an important troubleshooting aid by providing an
easy way to observe the status of individual ports and overall network operations.
1-6 Introduction
Specification
Provides one 1000BASE-ELX compliant LC fiber-optic single-mode port with a
standard LC connector. For optical and operating range specifications, refer to
"MGBIC-08 Specifications
Provides one 1000BASE-T compliant copper port with an RJ45 connector. For
port specifications, refer to
page A-7.
(1000BASE-ELX)" on page A-7.
"MGBIC-02 Specifications (1000BASE-T)" on
®
