Enterasys SecureStack C2 C2G124-24 Hardware Installation Manual page 71

Table A-1 Switch Specifications (Continued)
Item
Processors/Memory
Processor
Dynamic Random Access
Memory (DRAM)
FLASH Memory
Physical
Dimensions
Approximate Weight
C2G124-24
C2G124-48
C2H124-48
Predicted hours for Mean
Time Between Failures
(MTBF)
Heat Dissipation (maximum)
C2G124-24
C2G124-48
C2H124-48
AC Input Specifications
Input Voltage
Input Current
C2G124-24
C2G124-48
C2H124-48
Frequency
Specification
MPC8245, 400 MHz processor
256 MB
32 MB
4.4 H x 44.1 W x 36.85 D (cm)
1.7 H x 17.4 W x 14.5 D (in.)
Gross: 6.30 kg (13.9 lb) (shipping carton containing one module)
Net: 5.05 kg (11.1 lb) (one module without packaging)
Gross: 6.96 kg (15.3 lb) (shipping carton containing one module)
Net: 5.71 kg (12.6 lb) (one module without packaging)
Gross: 6.52 kg (14.3 lb) (shipping carton containing one module)
Net: 5.27 kg (11.6 lb) (one module without packaging)
For the MTBF hours for these products, refer to the MTBF web
site at URL
http://www.enterasys.com/support/mtbf/
@ 86.40 W, 294.80 Btu/hr
@ 129.50 W, 441.87 Btu/hr
@ 65.50 W, 205.80 Btu/hr
100 to 240 VAC
0.8 A Max
1.4 A Max
0.8 A Max
50 to 60 Hz
Switch Specifications
SecureStack C2 Installation Guide A-3
