High-Speed Stack Connections

The switches have rear‐panel connectors for high‐speed connections in a stack
configuration. The high‐speed stacking cables used for the connections are optional items
and must be ordered separately. Stacking cables are available in three lengths: 1 foot, 1
meter and 5 meters. See "Connecting High‐Speed Stacking Cables" on page 3‐11 for
details on these cables.

Redundant Power Supply Capability

The switch has power supply redundancy capability when connected to an optional
external redundant power supply (RPS). If the internal power supply fails, the RPS
assumes the entire load of the switch without interrupting network traffic. The internal
power supply and RPS each have their own AC power connection, which enables the
connection of each power supply to a different AC power circuit for additional AC power
source redundancy.

Connectivity

The switch connects to Ethernet networks or workstations via the fixed front panel RJ45
connectors and four uplink ports that support optional Mini‐GBICs.
At the time of this printing, the six Mini‐GBICs that are available from Enterasys are
described in Table
standard.
Table 1-1 Description of Mini-GBICs
Mini-GBIC
MGBIC-LC01
MGBIC-LC03
MGBIC-LC09
MGBIC-MT01
1‐1 on page 1‐5. These Mini‐GBICs meet or exceed the IEEE 802.3z‐1998
Specification
Provides one 1000BASE-SX compliant LC fiber-optic multimode port and a
standard LC connector. For optical and operating range specifications, refer to
"MGBIC-LC01 / MGBIC-MT01 Specifications
Provides one 1000BASE-SX compliant LC fiber-optic multimode port with a
standard LC duplex connector. For optical and operating range specifications,
refer to "MGBIC-LC03 Specifications
Provides one 1000BASE-LX compliant LC fiber-optic single-mode port with a
standard LC connector. For optical and operating range specifications, refer to
"MGBIC-LC09 Specifications
Provides one 1000BASE-SX compliant LC fiber-optic multimode port with a
standard MT-RJ connector. For optical and operating range specifications,
refer to "MGBIC-LC01 / MGBIC-MT01 Specifications
page A-5.
(1000BASE-SX)" on page A-5.
(1000BASE-SX)" on page A-5.
(1000BASE-LX)" on page A-6.
(1000BASE-SX)" on
SecureStack C2 Installation Guide 1-5
