CUSTOMER RELEASE NOTES
Known Issues in Previous Releases
The 03.02.30 code contains a new PoE driver which will require additional bootup time as the driver is being
updated on PoE units within the stack. Once the initial boot of the code has completed the delay should never be
seen again.
A RADIUS authenticated users session will not timeout on the expiration of the idle timeout.
RIP stops calculating cost properly if cost ever equaled 16. If route cost is reduced below 16, the cost will not be
propagated downstream properly.
The C2 does not allow secondary interfaces to be configured as owners of a virtual IP. The secondary interfaces
can only be configured as backups of the virtual IP.
The command ―set macauthentication portinitialize <port-string>‖ does not remove any currently active sessions.
Authenticated PWA sessions are not removed upon the expiration of the session timeout value returned from the
RADIUS server.
Users can now configure ―vlantag‖ tag rules for administering a phone policy, but the ―vlantag‖ option is no longer
supported for a policy profile index.
The MAC authentication portquietperiod defaults to 30 seconds.
A new user will not be able to re-authenticate under an existing session name until the current user logs off that
name.
If a FID is mapped to a sid through WebView, the action is executed, however if there are any fids currently
mapped to the sid they will be removed. Only the most recent mapping will be preserved.
Dynamic and static (admin) assignment of rule types is only supported for port-strings. The CLI output of ―show
policy capabilities‖ falsely lists numerous other rule types as supporting this functionality.
The host should not be configured with an ip address which contains .255 in any of the four octets. The device will
view any packets sent to this address as a subnet broadcast and the packets will be dropped, thus causing the
device to become unmanageable.
Downgrading code the on C2 device may result in loss of some configuration. If a user would like to downgrade
they should save their configuration, load the previous version of code on their device, set this older version of
code to be the boot code, and then reload the saved configuration onto the device. Note that you will not be able
to do this remotely unless you have remote console support.
If a user telnets to another device from the C2 and connectivity is interrupted to the device (i.e., spanning tree
failover) it takes approximately 9 minutes to close the telnet session. During this time the user cannot perform any
actions through the current connection.
If the CoS state is disabled but a CoS priority has been configured, the switch will continue to forward packets
with the CoS priority, however the ToS field will not be modified.
When setting the ip address on the device with the CLI command ―set ip address... ―, if the gateway is entered
before the mask, an error is returned and the ip address, mask and gateway are not configured. The user must
enter the host ip, then mask, then gateway for the command to be accepted.
If PWA is in auto mode for a port, and default policy is applied, attempting to remove the default policy fails until
PWA is disabled either by port or globally.
ACLs are not supported on routed VLANs which incorporate LAG ports.
Applying a policy to a destination port of a port mirror is not supported. Attempting to perform this will result in the
C2 resetting.
Policy ethertype rule does not VLAN classify SNAP packets. If a policy rule is configured for ethertype, SNAP
packets will not be VLAN classified according to their ethertype. AppleTalk ARP packets are SNAP encapsulated.
The OSPF ABR doesn't insert the default route into the NSSA when using the command ―area 0.0.0.8 nssa‖. The
default does get inserted when using the command ―area 0.0.0.8 nssa default-information-originate‖.
Policy VLAN egress is not supported.
When issuing the command ―show ip dvmrp route‖ the ―via neighbor‖ field returns a network prefix rather than the
IP address of the next hop gateway.
The output of ―show ip mroute‖ will incorrectly display the source mask address as 0.0.0.0.
The C2 does not support the ability for a user to configure the host's gateway to be a local routed interface
IP. The host's gateway must exist on a different device in the network if one is configured.
Port LEDs on the C2G134-24P are green if a port has a link regardless of if the link is PoE or data.
The C2 device is now propagating GVRP packets containing any known VLANs. If the user creates a VLAN
without adding ports to the egress list, it will begin propagating GVRP packets with that VLAN.
08/13/2008 P/N: 9038155-52
Subject to Change Without Notice
Page: 33 of 41
