Shimadzu iMLayer Installation Requirements page 10

225-25316
STEP-DOWN TRNASFORMER 1.5K
Connects to either 240V, 230,V 220V, or 200V
terminal according to power supply voltage
Yellow/Green(E)
225-25318-41
CABLE ASSY, IMSCOPE PS2
OUT
iMLayer
To iMScope AC100V in
225-25319-41
CABLE ASSY, IMSCOPE PS3
Fig 4 How to install the step- down transformer, TBX - 1.5KVA
240V
Brown(L)
230V
220V
P
200V
Blue(N)
0
Brown(L)
100V
0
Black S
a
Blue(N)
b
Earth Terminal
(Outside)
225-25320-41
CABLE ASSY, IMSCOPE EARTH
9
ZEBV-5088C
Earth Terminal
(Inside)
IN
225-25317-41
CABLE ASSY, IMSCOPE PS1
To power supply
To protective earth
