Module programming

Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes.
(For security-only programming, see next section.)
Please ensure that the vehicle is in a safe location, and cannot move forward during
1
programming. For vehicles equipped with a manual transmission, make sure the
gearshift lever is in the neutral position.
Connect all the harnesses to the DS4+ module, EXCEPT the 12-pin main power
2
harness.
Connect the 12-pin main power harness, and wait until the LED turns ON solid red.
3
Note: To skip the transponder programming and use convenience features only, press
the programming button 5 times. When the LED turns ON solidorange, proceed to
step 4.
Important: Do NOT press the brake pedal.
4
Press the Push-to-Start (PTS) button once to turn ignition ON. The LED flashes orange.
5
The LED turns ON solid green for 3 seconds, then turns OFF.
Press the PTS button once more to turn the ignition OFF, once the module is successfully
6
programmed.
Pair remotes (if applicable). For information on how to pair a specific remote, please
7
refer to its corresponding owner documentation, which can be found inside the product
packaging of the complete system or on www.directechs.com.*
By default, the tachometer is preprogrammed for the vehicle. For instructions on how to
8
program tach, refer to "Initialize Virtual Tach (not needed with hardwired or data tach
applications".
* Your aftermarket remote may differ from the model shown in the illustrations.
You have successfully completed the module programming sequence.
