Configuring the system
DS3+
Flashing the module using your computer:
1. Disconnect the main module from any (+) 12V power source, then connect it to your computer using the XKLoader2.
2. Go to www.directechs.com using Internet Explorer; the configuration wizard will be displayed automatically. Follow the
instructions in the pop-up window that will be displayed when the module is detected.
DS4+
Once the module is installed in the vehicle, follow the wiring diagram(s) related to your installation. Launch the DirectLink
application on your mobile device, and select Configure DS4/DS4+. Follow the on-screen instructions to configure the system.
Note: Your system can also be configured using XKLoader2 on www.directechs.com.

8556T Temperature Sensor

The 8556T Temperature Sensor is optional, but included with your DS3+/DS4+ module.
When used, the Temperature Sensor must be plugged into the 2-pin black connector of your module.
Note: When the system is configured as a remote starter, the temperature is reported by the 8556T
Temperature Sensor. When security features are enabled, it is reported by the 8504D Combo Sensor.

8504D Combo Sensor

The 8504D Combo Sensor is optional, but included with the purchase of a DS4SU security package.
The Combo Sensor is preset for the majority of applications; however, it can be adjusted using the DirectLink
application, as well as a compatible LED or LCD remote. Please refer to the instructions included with the DS4SU
for more information on how to make adjustments.
Note: When the system is configured as a remote starter, the temperature is reported by the 8556T Temperature
Sensor. When security features are enabled, it is reported by the 8504D Combo Sensor.

IMPORTANT:

Pairing
To enter pairing:
1
Open the driver side door.
Turn the vehicle ignition to the ON position.
OR
2
Press the PTS button to turn the ignition ON.
* The number of times the PTS button is pressed depends on the vehicle.
Within 10 seconds, press and release once, and then press and hold
the programming button on the Control Center (antenna) or the
LED/Valet Pod (standalone switch) until the LED starts flashing then
3
release the button.
* Your antenna may differ from the model shown in the illustration.
Note: Connected devices become registered within 4 to 6 seconds.
11
933.VW08 1.39.195.3 2019 Audi Q8 (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
The Combo Sensor must be paired to the device before it can be used.
Key OUT Key IN
START START
& &
Press &
Release
Key IN Key IN
OR
START START
* *
OR
&
