13) W IRING D IAGRAM
Control b oard
No Function
1 Magnet N egative O utput
2 Magnet P ositive O utput
3 Mains N eutral I nput
4 Motor N eutral O utput
5 Motor L ive O utput
6 Mains L ive I nput
No Function
A Power ' ON' L ED 0 V
B Power ' ON' L ED + 12V
C Magnet ' ON' L ED 0 V
D Magnet ' ON' L ED + 12V
E Magnet S witch 0 V
F Magnet S witch + 12V
G Motor ' Start' L ED 0 V ( Green)
H Motor ' Stop' L ED + 12V ( Red)
I Motor ' Stop' S witch 0 V
J Motor ' Stop' S witch + 12V
K Motor ' Stop' L ED 0 V ( Red)
L Motor ' Start' L ED + 12V ( Green)
M Motor ' Start' S witch 0 V
N Motor ' Start' S witch + 12V
12
Original i nstructions
Display B oard
Wire C olour
Black
Red
Blue
Black
Red
Brown
Wire C olour
Red
Red
Red
Red
Red
Red
Red
Red
Red
Red
Red
Red
Red
Red
