Element 50 AUTO Manual

15) WIRING DIAGRAM

No
1
Mains Live Input
2
Speed controller module Lead wire
3
Speed controller module Lead wire
4
Mains Neutral Input
5
Magnet Positive Output
6
Magnet Negative Output
7
Field coil Lead wire
8
Field coil Lead wire
9
Carbon brush Lead wire
10
Carbon brush Lead wire
Original Instructions
Function
Wire Colour
Brown
White
Red
Blue
230V Red,110V Blue
Black
Blue
Green
Black
Brown
15
June 2022
