7) C ONTROL P ANEL O PERATION
1) P ower
When t he d rill i s c onnected t o
the p ower s upply, t he R ED L ED
will i ndicate p ower t o t he d rill.
4) M otor O N
Press t he G REEN S witch t o t urn
the m otor o n. P roceed w ith
cutting-­‐ f ollowing a ll s afety
guidelines...
CutSmart2™ T echnology
Green Z one Yellow Z one
Perfect, t ry t o k eep i n A l ittle t oo m uch
the g reen z one f or pressure o n t he d rill
the b est c ut a nd ease o ff t o g et b ack
optimum m achine to t he g reen z one.
performance.
8
Original i nstructions
2) M agnet O N
To t urn t he m agnet O N o r O FF,
depress t he l arge b utton o n t he
control p anel. A G REEN L ED w ill
indicate t he m agnet i s O N.
5) C utting
See b elow f or d etailed
description o f t he C utSmart2™
visual i ndicator
CutSmart2™ T echnology
Designed f or y ou t o g et t he m ost o ut o f y our
machine a nd y our c utters. C utSmart2 h as a n
easy t o r ead p anel t hat i ndicates w hen y ou
are d rilling w ith t oo m uch f orce, w hich w ill
damage t he m achine a nd t he c utters.
Red Z one
Allow t he c utter t o d o t he w ork a nd y ou w ill
Overload: B ack o ff
immediately a s t oo
find t hat a m uch s moother h ole a nd f aster
much f orce w ill c ause
drilling t ime i s a chieved.
the m otor t o c ut o ff i f
you c ontinue.
3) M otor s witch
When t he m agnet h as p ower t he
GREEN s witch w ill l ight u p t o i ndicate
motor s tart.
6) M otor O FF
To s top t he m otor p ress t he R ED
switch. T he m otor w ill s top a nd t he
magnet w ill r emain o n. T he G REEN
switch w ill t urn o n.
Go b ack t o s tep 3 t o s tart o ver.
