6.14 HIGH SPEED INTERFACE CONFIGURATION
SCREEN
The High Speed Interface Configuration screen, Figure 6-13, applies only
to ports 15 and 16. This screen supports the FE-100TX and the FE-100FX
Fast Ethernet Interface Modules that operate at 100 Mbps.
The High Speed Interface Configuration screen displays the types of
interfaces installed in ports 15 and 16, their current operating mode, and
indicates if the ports are linked. This screen also allows the user to enable
or disable Auto-Negotiation and set the Advertised Ability.
The High Speed Interface Configuration screen is accessed from the
Device Specific Configuration Menu screen by using the arrow keys to
highlight the High Speed Interface Configuration option and pressing
ENTER. The High Speed Interface Configuration screen appears.
Event Message Line
Device Name: 8H02-16
Port Type
Link Status
Current Oper. Mode
Desired Oper. Mode
Advertised Ability
SAVE
Figure 6-13 High Speed Interface Configuration Screen
8H02-16 User's Guide
High Speed Interface Configuration Screen
8H02-16 LOCAL MANAGEMENT
High Speed Interface Configuration
Port 15
FE-100TX
Link
100Base-TXFD
[Auto-Negotiation]
[100Base-TXFD] [Disabled]
Firmware Revision: XX.XX.XX
BOOTPROM Revision: XX.XX.XX
Port 16
N/A
No Link
[N/A]
[N/A]
[N/A]
RETURN
