Altronix NetWay V Series Installation Manual page 7

NetWay8V/NetWay16V Rack Mount Chassis
Fig. 6
0.75" (19.1mm)
AC POWER
1.625" (41.3mm)
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user
to the presence of an insulated DANGEROUS VOLTAGE within the product's enclosure that may be of
sufficient magnitude to constitute an electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of impor-
tant operating and maintenance (servicing) instructions in the literature accompanying the appliance.
NetWay8V / NetWay16V Installation Guide
Mechanical Drawing and Dimensions:
(ON)
CAUTION: To reduce the risk of electric shock do not open enclosure.
There are no user serviceable parts inside.
Refer servicing to qualified service personnel.
19.125" (485.8mm)
17.625" (447.7mm)
- 7 -
