Altronix NetWay V Series Installation Manual page 3

Port Status
All Ports Off
Port Off
Port On
Class 4 detection Port
Non-compliant Device
Port Overload Fault
4 Port Overload Grouped
8 Port Overload Grouped
Fig. 1 - NetWay8V/NetWay16V Configuration
NetWay8V - Front Panel
NetWay16V - Front Panel
NetWay8V & NetWay16V - Rear Panel
AC POWER
1d 1e
1a OUT 1-8 (NetWay8V), OUT 1-16 (NetWay16V): Structured cable to PoE compliant cameras/edge devices.
1b IN 1-8 (NetWay8V), IN 1-16 (NetWay16V): Structured cable to ethernet switch or video server.
1c LED(s) 1-8 (NetWay8V), 1-16 (NetWay16V): Port status LEDs.
1d Illuminated master power disconnect circuit breaker (switch):
• OFF position Circuit breaker tripped. Switch not illuminated.
• RESET (ON) position. Switch illuminated.
1e IEC 320 Connector: 115VAC 60Hz (grounded line cord included).
NetWay8V / NetWay16V Installation Guide
Port Status and LED Flash Codes:
Flash Codes
Sequential LED Port Scan
OFF
ON
Blinks 2 times
2Hz
5Hz
5Hz
5Hz
1a 1b
Description
No devices connected
LED OFF
LED ON
Enables power to PoE devices.
Will prevent port from turning on.
Will prevent port from turning on.
Will prevent ports from turning on.
LED's 1-8 Power Supply Overload for ports 1-8.
LED's 9-16 Power Supply Overload for ports 9-16.
4 LEDs
1c
- 3 -
