Cylinder AX Modularity
(Manual)
Extractor (Z5.LIFTER)
The Cylinder AX thumb-turn assembly tool is designed so that you can use
it as a bracket for the Cylinder AX. Place it with the flat side on a flat
surface and place the Cylinder AX with the knob in the assembly tool.
Reassembly is easier if the AX cylinder is in the bracket.
SPACER (Z5.SPACER)
3. Accessories and tools
7 / 62
Terminal BLOCK
(Z5.BLOCK)
