8. On the Spectrum Master, press and hold the
turn on the Spectrum Master. (This sets the instrument to the factory preset state.)
9. Press the
MODE
.
ENTER
10. On the MG3692A press the Level key, then use the knob to adjust the power level so that the
power meter reads -40 dBm.
11. Verify that the Spectrum Master reading is -40 dBm ± 1.0 dB.
12. Repeat steps 10 and 11 for the other power level settings shown in
Table 8. Power Monitor Test Levels
18
key. Use the Up/Down arrow key to highlight
Power In @ 1 GHz
0 dBm
-7 dBm
-21 dBm
-40 dBm
key, then press the
ESCAPE/CLEAR
Power Monitor
Specification
± 1 dB
± 1 dB
± 1 dB
± 1 dB
key to
ON/OFF
and then press
Spectrum Master MM
