P U S H - T O - O P E N
44
STEP 2. Post bracket pre-assembly.
YOU WILL NEED TO MAKE SURE YOU PURCHASE THE PUSH-TO-OPEN BRACKET KIT (AXPO) BEFORE
YOU START THIS STEP
Insert the M10x1.5x75mm bolt and M10 washer through the hole that is closest to the post on the post bracket. Bolt should
then go through first push-to-open bracket, pivot spacer, second push-to-open bracket, and exit bottom hole of post bracket
as shown. Fasten a M10 washer and M10 locknut on the end of the bolt.
DO NOT overtighten the nuts because the Push-To-Open brackets may need to be adjusted later.
EXPLODED
PUSH-TO-OPEN
BRACKET
NYLON PIVOT SPACER
PUSH-TO-OPEN
STEP 3. Clamp post bracket to post for alignment.
After the post bracket is pre-assembled and the horizontal centerline has been marked on the post as referred to in
STEP 2 and 3, then proceed to CLAMP THE POST BRACKET TO THE MARKED CENTER LINE on the post.
Align bracket ush
with edge of post.
© G h o s t C o n t r o l s 2 0 1 9
M10 X 1.5 X 75MM BOLT
M10 WASHER
M10 WASHER
BRACKET
M10 LOCKNUT
POST
BRACKET
CL
COMPLETED ASSEMBLY
