Ghost Controls DEP2 Installation And Owner's Manual page 36

P U L L - T O - O P E N
36
B. Install the front mount gate bracket and estate bracket on the gate by aligning the outermost hole of both
brackets and inserting (1) M8 x 65mm flat washer, and (1) M8 nylon locknut through both the estate and
front mount bracket, as show below. Tighten to secure the brackets to the gate. MAKE SURE GATE IS STILL
IN OPEN POSITION (arm must be fully retracted).
Estate Bracket install
on backside of gate
C. Disconnect operator from gate bracket and swing away from the gate.
D. Assemble clevis pin, front spacer and hair pin to operator to prevent loss.
E. Now you can mark and drill the inner most hole on the front mount bracket, shown below.
Mark and drill
center location of
innermost hole
Front Mount Bracket
CL
Remove the clevis pin,
hair pin, and front spacer.
Temporarily assemble cotter pin,
hair pin, and front spacer into
front mount
