13.3.4.3 Frequency converter operation
13.3.5 Commissioning
13.3.6 Maintenance and repair
13.3.6.1 Repair of housing coating
13.3.6.2 Replacing the connection cable
13.3.6.3 Changing the mechanical seal
Installation and operating instructions Wilo-Flumen OPTI-TR 20-1, 22, 28-1, 30-1, 40-1, Wilo-Flumen EXCEL-TRE 20, 30, 40
Appendix
ƒ
Converter type: Pulse-width modulation
ƒ
Min./max. frequency during continuous duty:
–
Asynchronous motors: 30 Hz up to rated frequency (50 Hz or 60 Hz)
–
Permanent magnet motors: 30 Hz up to the stated maximum frequency as per
rating plate
NOTICE! The maximum frequency may be below 50 Hz!
ƒ
Min. switching frequency: 4 kHz
ƒ
Max. overvoltage at the terminal board: 1350 V
ƒ
Output current at the frequency converter: max. 1.5 times rated current
ƒ
Max. overload time: 60 s
ƒ
Torque applications: quadratic pump curve or automatic energy optimisation pro-
cedure (e.g. VVC+)
Required speed/torque curves are available on request!
ƒ
Observe additional measures with regard to EMC regulations (choice of frequency
converter, filters, etc.).
ƒ
Do not exceed the rated current or rated speed of the motor.
ƒ
It must be possible to connect the motor's own temperature monitoring (bimetallic
strip or PTC sensor).
ƒ
If the temperature class is marked as T4/T3, temperature class T3 applies.
DANGER
Risk of explosion when using non-Ex-rated mixers!
Risk of fatal injury due to explosion! Only use mixers which have Ex labelling on the
rating plate within potentially explosive areas.
ƒ
The operator is responsible for defining the potentially explosive area.
ƒ
Only Ex-rated mixers may be used within potentially explosive areas.
ƒ
Mixers with an Ex rating must be labelled as such on the rating plate.
ƒ
Do not exceed the max. fluid temperature!
ƒ
According to DIN EN 50495, a safety device with SIL level 1 and hardware fault toler-
ance 0 must be provided for category 2.
ƒ
Carry out maintenance tasks according to the regulations.
ƒ
Only carry out maintenance tasks described in these installation and operating in-
structions.
ƒ
The spark-proof gaps must only be repaired according to the manufacturer's design
specifications. Carrying out repairs according to the values in tables 1 and 2 of DIN
EN 60079-1 is not permitted.
ƒ
Only use screws as stipulated by the manufacturer, which at a minimum correspond
to a strength class of 600 N/mm² (38.85 long tons-force/inch²).
The paint layer can become electrostatically charged in case of thicker
coats.DANGER! Risk of explosion! In explosive atmospheres, a discharge can cause
an explosion!
If the housing coating has to be repaired, the maximum coat thickness is 2 mm
(0.08 in)!
Changing the connection cable is strictly prohibited!
Changing the seal on the motor side is strictly prohibited!
