Technical data
Main features
Parameter
Measuring inputs
Control or flow inputs
Floor tank
Outputs
Relay
Pumps
Pump types
Pumps
Communication
74
Specification(s)
1x potentiometric (pH) 0 ... 14 pH.
1x potentiometric (ORP) 0 ... +1000
mV.
1x RTD (4..20mA) -5 ... 45 °C.
1x remote input in "Control On/Off"
Control 1x flow switch detection
1x inlet floor tank for pH measuring
channel
1x floor tank inlet for ORP measuring
channel
1x current relay, mains power supply
contact 250 mA / 230 VAC
2x current relay, mains power supply
contact 250 mA / 230 VAC
Metering pumps with 4 different feed
rates:
0.4 l/h,
0.8 l/h,
1.6 l/h,
2.4 l/h,
Acid- and oxidation-resistant pipes.
Markings(s)
PH
ORP
TEMP
SPDT1
SPDT4
SPDT2
SPDT3
RELAY
PUMP1
PUMP2
