Probe:
1X position
Bandwidth Up to 6 MHz (DC)
Attenuation rate 1: 1
Compensation 10pf~35pf
range
Input resistance 1MΩ±2%
Input impendence 85pf~115pf
Input voltage 150 V DC

Meter

Voltage (VDC)
Input Impedance: 10MΩ.
Max. Input Voltage: 1000V (DC or AC peak-to-peak value)
Range
400.0mv
4.000V
40.00V
400.0V
Voltage (VAC)
Input Impedance: 10MΩ.
Max. Input Voltage: 750V (AC, virtual value)
Frequency range: from 40Hz to 400Hz.
Display: Virtual value of the sine wave
Range
4.000V
40.00V
400.0V
Direct Current (DC):
Range
40.00mA
300.0mA
20A (with adaptor)
Alternating Current (AC):
Range
40.00mA
300.0mA
20A (with adaptor)
10X position
Up to full bandwidth (DC)
10: 1
10MΩ±2%
14.5pf~17.5pf
300 V DC
Accuracy
±1%±1 digit
Accuracy
±1%±3 digits
Accuracy
±1%±1 digit
±1.5%±1 digit
±3%±3 digits
Accuracy
±1.5%±3 digits
±2%±1 digit
±5%±3 digits
49
Resolution
100uV
1mV
10mV
100mV
Resolution
1mV
10mV
100mV
Resolution
10uA
100uA
10mA
Resolution
10uA
100uA
10mA
MS400 Version 2.0 – December 2007
