Using the four keys OSC LEFT, OSC RIGHT, OSC UP and OSC DOWN, users
can make the following settings by pressing OSC OPTION. The settings include:
Voltage Unit Scale for Channel 1 (CH1 VOL); Voltage Unit Scale for Channel 2
(CH2 VOL); Primary Time base (TIME BASE), zero point position for Channel 1
(CH1 ZERO), zero point position for Channel 2 (CH2 ZERO), trigger horizontal
position (TIME) and trigger level position (TRIG).
When performing Waveform Calculations, users can also adjust and calculate the
Display Multiplying Factor of a Waveform (CHM VOL) and the vertical display
position (CHM ZERO).
In cursor measurement mode, users can adjust the positions of Cursor 1 (V1 or
T1) and Cursor 2 (V2 or T2).
12. OSC DOWN: Oscilloscope display downward adjustment key.
13. OSC UP: Oscilloscope display upward adjustment key.
14. OSC/DMM: Press to switch between oscilloscope and multimeter.
15. AUTO SET:
In the Multimeter Mode, when performing a current or voltage measurement, the
user can switch between AC and DC with this key; when performing a resistance
measurement, the user can select resistance, diode, On/Off or a capacitance
measurement with this key.
This key is used for auto setting in the oscilloscope operation mode.
16. RUN/STOP: key for starting or stopping an operation.
17. MENU DOWN: Move down the menu list.
18. MENU: Show / Hide the menu.
19. MENU UP: Move up the menu list.
20. F1～F5: Switch or Adjustment options for each menu
