Section 10
Specifications

General Specifications

•
•
•
•
•
•
•

Additional Features

•
•
•
•
•
•
•
46
Model 2001 Service Manual
Operating Conditions:
50-104° F (10-40 °C), 0-90% relative humidity, non-condensing
Transport/Storage Conditions:
-10 to +55°C (14-131°F), 10-95% relative humidity, non-condensing
Weight: 7 lbs 5 oz. (3.32 kg)
Dimensions:
Height, 3.3 inches (8.38 cm) Width, 9 inches (22.86 cm) Depth, 8 inches (20.32 cm)
Power: 100-120/200-240 VAC, 50/60 Hz
Fuse Rating:
U.S.A.: 0.5 A, 250 V, Slo-Blo (x2) European: T 250 mA/250 V (x2)
Battery:
Type, lead-acid gel-cell. Battery Life, 3 hours.
Note: Excessive alerting reduces battery life. When 15 minutes of battery life remain, the
(low battery) indicator illuminates. When the battery becomes exhausted, the monitor
display shuts down. Connect to AC power to recharge battery. Recharge Time, battery
fully recharged in 12-15 hours maximum.
2 Minute Silence:
When AUDIO key is pressed, deactivates audible alerts for two minutes.
Indicated by illuminated
Audio Off:
Feature user selectable. If enabled, press and hold
audible alarms will not activate.
Indicated by flashing
Battery Backed Trend Memory:
Trend memory print of any 30 minutes, 2 hours, 8 hours 12 hours or 24 hours when used
with the Seiko DPU-414 Thermal Printer.
Analog (Recorder) Output Module - Optional:
Provides analog output for strip chart applications at the following levels:
Oxygen Saturation value, 10mV/% (100% = 1 V)
Pulse Rate value, 4mV/bpm (250 bpm = 1 V)
Plethysmograph pulse waveform, 0-1V max (AGC)
Serial (RS232) Data Output:
Provides RS232 data interface compatible with;
Seiko DPU-414 Thermal Printer
Novametrix Model 1260 Capnograph
Novametrix Model 1010 Telemetry Central Station
RS232 computer interface
NovaCARD Memory Module
NOVACOM1 Interface
Internal Real Time Clock
Alert Bar
(2 Min LED).
(OFF LED).
General Specifications
AUDIO key for 3 seconds, and
Rev. 01
