Section 11
Accessories
Catalog No. Description
8791-36 Y-36 Plan The Plan length is 36 months. Includes 9 boxes of any Y-Strip Taping Systems
8791-60 Y-60 Plan The Plan length is 60 months. Includes 15 boxes of any Y-Strip Taping Systems
8776-36 Finger-36 Plan The Plan length is 36 months
8776-60 Finger-60 Plan The Plan length is 60 months
8828-00 20mm Wrap Style Taping System (100 per box)
8829-00 25mm Wrap Style Taping System (100 per box)
8831-00 20mm Finger Style Taping System (100 per box)
8832-00 25mm Finger Style Taping System (100 per box)
6929-00 Adhesive Foam Wraps - Large (25 per box)
6968-00 Adhesive Foam Wraps - Small (25 per box)
8836-00 Non-Adhesive Foam Wraps - Large (25 per box)
8943-00 Non-Adhesive Foam Wraps - Small (25 per box)
6131-50 Ear Clips (5 per box)
6131-25 Ear Clips (25 per box)
8700-00 Adhesive Dots (200 per box)
9140-00 Seiko DPU-414 Thermal Printer, with battery pack
48
Model 2001 Service Manual
SE N S OR MA NAGEME N T PL AN S
Select a Finger Sensor or Y-Sensor™ Management Plan for each SuperBright™ Pulse
Oximeter. The plan you select determines the length of coverage—36 or 60 months.
How the Plans Work: Included in each Plan are TWO sensors—one for immediate use, the
other one for back-up. If a sensor becomes inoperative, place the backup sensor into use and
return the inoperative sensor in the convenient prepaid mailer. A replacement sensor will be
shipped within two business days of receipt of the inoperative sensor. This simple return/
replacement method will be used for the entire warranty period, thereby, guaranteeing your
costs and virtually eliminating sensor tracking hassles.
Warranty: For each Pulse Oximeter a plan is purchased for, the warranty on the monitor is
also extended to the length of the Plan (a pre-contract inspection may be required).
Replacement sensors provided under terms of the Plan shall carry the remaining Plan
warranty—replacements do not extend the warranty.
Y- S E NS O R ™ AP P L I CATO R S ( ta p e s, w r a ps, e ar c li ps)
Use on neonatal foot and hand, or on pediatric toe or finger
20mm tapes use Blue color-coded liners
Use on neonatal foot and hand
25mm tapes use Green color-coded liners
Use on pediatric finger or on small adult finger
20mm tapes use Blue color-coded liners
Use on adult finger
25mm tapes use Green color-coded liners
PR IN TE RS
Model 2001 Pulse Oximeter
