Novametrix Medical Systems MARS PO2 TECH 2001 Service Manual page 64

Section 12
Parts Lists
Seq
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
000
2485-01 ANALOG MODULE BOARD ASSEMBLY
Seq
001
002
003
004
005
006
007
008
009
010
011
012
013
014
015
016
017
018
019
020
021
022
58
Model 2001 Service Manual
Item Nbr Description
600034 RIBBON CABLE ASS?, 4
474181 RESISTOR, 4.3 OHM, 1
474166 RESISTOR, lOOK OHM,
474216 RESISTOR, 4.99K OHM,
485543 TRANSISTOR, MOSFET,
2726-03 SCHEMATIC, POWER SUP
211213 CONNECTOR, 2 PIN, HE
481552 DIODE, MBRS34OT3, SC
154072 CAPACITOR, .1UF, 50V
474151 RESISTOR, 37.4K OHM,
484559 VOLT RGLR, LT1O76CT
515083 FUSE W FUSEHOLDER, 1
2726-17 POWER SUPPLY BOARD 5
154079 CAP, 1OUF, 25V, 20~,
474218 RESISTOR, 47.5K OHM,
280114 SNAP RIVET, .118- .15
152029 CAPACITOR, 220UF 20%
485532 TRANSISTOR, 2N7002T1
474211 RESISTOR, 49.9K OHM,
481561 DIODE, ULTRAFAST, 3A
474341 RESISTOR, 4.3 OHM, 3
481563 DIODE, SCHOTTKY, SA,
Item Nbr Description
2485-02 FAB, ANALOG OUTPUT CONTROL BD
2485-03 SCHEMATIC, ANALOG MODULE
5894-10 RIBBON CABLE, ANALOG MODULE
154072 CAPACITOR, .1UF, 50V, 10%
154079 CAP, 10uF, 25V, 20%, TANT
154080 CAPACITOR, 47UF, l0VDC, 1
154082 CAPACITOR, 22PF, 100V, 10
212310 CONNECTOR, 15 PIN, RECEPT
215042 SOCKET, 28 PIN, TURNED
230021 CRYSTAL, 4.9152MHZ, HC-49
470008 RESISTOR, 4.7 OHM, 1/4w,
474138 RESISTOR, 100 OHM, 1/8w,
474146 RESISTOR, 21.5K OHM, 1/8w
474161 RESISTOR, 5.9K OHM, 1/8w
474165 RESISTOR, 10K OHM, 1/8w
474169 RESISTOR, 7.5K OHM, 1/8w
481027 DIODE, ZENER, LM385BZ-2.5
481547 DIODE, BAT54, HOT CARRIER
484546 VOLTAGE CONVERTER, LTCl04
485532 TRANSISTOR, 2N7002T1, N-C
486029 IC, HD63B03RB, CMOS
486309 IC, 7528, DUAL 8-BIT D TO A
Qty
1
1
4
1
1
0
1
3
4
1
1
1
1
1
1
0
1
1
1
1
1
2
Qty
1
0
1
32
3
1
2
1
1
1
1
6
8
3
3
7
1
3
1
1
1
3
Rev. 01
