Section 8
Maintenance
Assembly Exchanges
The disassembly instructions below are intended as a guide to enable component exchanges
if necessary. There are no serviceable parts inside. Disassembly should be performed by
qualified service personnel only.
7.
Ensure the monitor is Off. Disconnect the line cord and sensor. Remove the four cover screws
from the bottom cover. Holding both case halves together, flip the monitor right-side up.
8.
Lift the top cover from the monitor. Use a gentle rocking motion to lift first one side and then the
other side a little at a time. Set the Red Alert Bar lens aside with the cover for safe keeping.
40
Model 2001 Service Manual
1
5
6
4
Assembly Exchanges
2
3
7
Rev. 01
