Novametrix Medical Systems MARS PO2 TECH 2001 Service Manual page 65

Seq
023
024
025
026
5963-00
Seq
001
002
003
004
005
006
007
008
009
010
011
012
013
014
015
016
017
018
Rev. 01
Item Nbr Description
486317 IC, MC74HC00AD
486321 IC, SN74HCl38D
486323 IC, SN74HC573DW
486783 IC, TL034ACD
ANALOG MODULE
Item Nbr Description
2485-01 ANALOG MODULE BOARD ASSEMBLY
5895-13 HOUSING, PAINTING & SHIELD
5970-07 PROGRAM, EPROM ASSY
5982-10 BACKPLATE, ANALOG MODULE
161059 TAPE, FOAM, POLYETHYLENE,
280197 STANDOFF, 3/16 HEX X 5/8L
280198 STANDOFF, 3/16 DIA X 3/8L
280187 STANDOFF, .187 DIA x 5/8
284003 SCREW, NO. 4 X 1/4L, SELF
284200 #4-40 X 1/4 SLOTTED BINDI
284203 #4-40 X 3/16 SLOTTED BIND
284207 #4-40 X 3/8 BINDING HEAD
284253 #4-40 X 1/4 OVAL HEAD PHI
6120-32 INSTRUCTION SHEET
280212 SCREWLOCK KIT, FEMALE
285000 LOCK WASHER, NO. 4
161092 ADHESIVE, 262, THREADLOCK
6070-32 LABEL, SERIAL NUMBER
Section 12
Parts Lists
Qty
1
1
1
2
Qty
1
1
1
1
0
0
0
0
0
0
0
0
0
1
1
0
0
1
Model 2001 Service Manual
